NaiRoute · built on QGIS · on-premise

Software for runningan underground fibernetwork.

Maps, ports, splices, and customers stay in one shared database.

Book a technical demoSee the workflowCustomer sign-in
Underground FTTx
One shared database
Built on QGIS
Deployed on-premise

Today, your network lives in files.

KMZ exports, spreadsheets, printouts, and memory. When the person who knows is unavailable, work stops.

Maps
NameDate modifiedSize
  • old_maps2023-02-11
  • aqaba_north.kmz2024-06-302.1 MB
  • aqaba_north_FINAL.kmz2025-11-022.4 MB
  • aqaba_north_rev3.kmz2026-01-182.4 MB
ports_field (copy).xlsx
ports_office.xlsx
ABC
110360Fadi CalvertP14
24352Hadi NorwoodP12
34341Sara NorwoodP14
44359Maya MardenP08

DOH-0136 · SPLICE SHEET

1blueNadia Calvert
2orangeJad Marden
3greenRana Calvertmoved?
4brownHana Calvert

  1. 01Scattered geometry

    Every KMZ export is a snapshot nobody trusts a month later.

  2. 02Spreadsheet assignments

    Port assignments and subscriber records are copied between spreadsheets until the files disagree.

  3. 03Paper splice records

    What’s inside each closure lives on a printout in a van, if anywhere.

  4. 04Knowledge in heads

    Which customers go dark if this duct is cut? The answer lives in one engineer’s head.

The product, live

Planning, support, splicing, and reporting each have a working screen below.

Four live workspaces

Living Map

See every duct, cable, closure, and customer together, with the right detail at each zoom.

Toggle Focus mode and layers, then select a house to trace its path.

23622324DUCT-0002DUCT-0005DUCT-0006DUCT-0007DUCT-0008DUCT-0009CBL-0002 48FCBL-0003 48FSC-003SC-013SC-015SC-002SC-008SC-010DOH-0029DOH-0011DOH-0136DOH-0107DOH-0035DOH-0214DOH-0130DOH-0033DOH-0085DOH-0151DOH-0124DOH-0038POP-01NAP-0001

LAYERS

EPSG:32636Click a service point to trace its recorded path.

Customer Desk

Find a customer, inspect their assigned path and port, or record a fault while they are on the line.

Search the list, change filters, or select a port in the matrix.

CUSTOMER DESK

customer, equipment, ports

78 customers 4 need assignment

Sara Norwood (4341)

ActiveID 4341Partner B
Edit
SERVICE ASSIGNMENT Live · signal path complete
ODFT4 · P2
SplitterM1 · P59
CabinetSC-015
Drop closureDOH-0107
CustomerSara Norwood
Assignment complete. DOH, cabinet, splitter and ODF are captured per sheet.
CUSTOMER
Customer ID4341
PhoneNot recorded
PartnerPartner B
ServicePrimary
NETWORK
Drop closureDOH-0107
CabinetSC-015
SplitterModule 1 · Port 59
ODFTray 4 · Port 2
PORT MATRIX
SC-015 · 31/64 · next P07

Splice Studio

Connect individual fibers on screen and print the same closure sheet for the crew.

Pair fibers across the joint, or preview and apply a complete range.

SPLICE STUDIO

DOH-0136 · pass-through cut & drop

Switch to snip view
Sheet complete
CBL-0002 · 48FCBL-0003 · 48F
Tube 1
Tube 2
Tube 1
Tube 2

Network Console

Open a complete offline copy of the network from one file, without a server, login, or internet connection.

Switch tabs or select an alert to open the related record.

Demo Network

Aqaba, Jordan

78 subscribers

Generated 2026-07-18 12:43 UTC

NEEDS ATTENTION

2POPS
15CABINETSsplitter SCs
8SPLITTER MODULES
40CLOSURES23 shared
78SUBSCRIBERS5 partners

6.56 km cable · 11.77 km duct · underground plant, Aqaba, Jordan

PARTNER MIX78 total
Partner B3747%
Partner D2633%
Partner C912%
Partner A56%
Demo Networkself11%
SERVICE BREAKDOWN
Primary
33
Shared drop
38
Cabinet-fed
6
Return
1
Book a technical demo
deyaaldeen.alsoub@outlook.com+962 79 810 3323

How the record gets built.

Each step records what the next one depends on.

  1. 01 · IMPORT

    Import existing plant

    Import KMZ maps and subscriber sheets, then review every change before it enters the record.

    WRITTENaqaba_north.kmz

  2. 02 · DESIGN

    Design ducts and cables

    Route cables through ducts along mapped roads, using snapping and assisted routing.

    WRITTENCBL-0006

  3. 03 · CONNECT

    Connect closures and cabinets

    Every cable lands somewhere. Endpoints and duct membership are recorded, not implied.

    WRITTENCBL-0002 → DOH-0136

  4. 04 · ASSIGN

    Assign subscribers and ports

    Assign splitter ports without double-booking, even when two desks work at once.

    WRITTENSC-013 · P07

  5. 05 · SPLICE

    Record splices and ODF patches

    Record every fiber connection in the closure, then print the same sheet for the crew.

    WRITTENDOH-0136 · F07 to F12

  6. 06 · PROVE

    Validate, trace and export

    Trace any subscriber to their fiber path. Export the bill of materials, map atlas, or offline console.

    WRITTENEPSG:32636

The whole team edits at once.

Planning, support, and splice crews edit the same project. Conflicting port assignments are rejected before a record is overwritten.

DOH-0136SC-013PORT TAKENSC-013 / PORTS0102030405060708
CBL-0006 SAVED
PLANNING
SUPPORT
SPLICE CREW
PLANNINGDrawing CBL-0006SUPPORTAssigning SC-013SPLICE CREWSplicing DOH-0136

From scattered files to daily operation.

NaiRoute runs on your machines. Its database and QGIS project use formats that other tools can read.

  1. 01Week 1-2

    Review and migrate

    We inspect your KMZ and Excel files, import them, then compare the result with the source.

  2. 02Week 3-4

    Install and train

    We install NaiRoute on engineers’ machines and train the team using its own network data.

  3. 03Week 5-6

    Go live and support

    Annual support covers updates, fixes, and direct engineering help.

Book a technical demo
deyaaldeen.alsoub@outlook.com+962 79 810 3323

Custom software for your operation

DeyaAldeen AlSoub builds and supports NaiRoute in Amman, Jordan. He also turns each client’s existing procedures into software.
